CV-24V-HLG-320W- Non Dimmable LED Driver, IP65 HLG-320H-24A
11400
£114.00
Unit price perEstimated delivery between January 23 and January 25.
| Download Datasheet |
|
| Product Details ‒ Model: HLG-320H-24A | |
|---|---|
| Features | |
| Power Rating | 320 W Constant-Voltage LED Driver |
| Input Voltage | 90-305 VAC / 127-431 VDC (Universal Input) :contentReference[oaicite:0]{index=0} |
| Efficiency | Up to ~95% :contentReference[oaicite:1]{index=1} |
| Protections | Short circuit / Over current / Over voltage / Over temperature :contentReference[oaicite:2]{index=2} |
| IP Rating | IP65 / IP67 – suitable for indoor & outdoor installations :contentReference[oaicite:3]{index=3} |
| Cooling | Free-air convection, fanless design :contentReference[oaicite:4]{index=4} |
| Dimming | Non-dimmable / Single output; for this model CV only (no built-in dimming) :contentReference[oaicite:5]{index=5} |
| Output Specifications | |
| Output Voltage | 24 V DC :contentReference[oaicite:6]{index=6} |
| Rated Current | 13.34 A :contentReference[oaicite:7]{index=7} |
| Rated Power | 320 W :contentReference[oaicite:8]{index=8} |
| Voltage Adjustment Range | ≈ ±6% via output cable or internal potentiometer :contentReference[oaicite:9]{index=9} |
| Environmental & Regulatory Specs | |
| Operating Temperature | -40 °C to +70 °C (case); refer to derating curves for high ambient temperatures :contentReference[oaicite:10]{index=10} |
| Certifications / Standards | UL8750, TUV EN61347-1/2-13, etc. EMC / Surge immunity 4kV per IEC61000-4-5 :contentReference[oaicite:11]{index=11} |
| Mechanical / Physical | |
| Dimensions (L × W × H) | 252 × 90 × 43.8 mm :contentReference[oaicite:12]{index=12} |
| Weight | ~1.88 kg :contentReference[oaicite:13]{index=13} |
| Warranty | 7 years (manufacturer) :contentReference[oaicite:14]{index=14} |
