CV 24V-HLG-40W- Non Dimmable LED Driver, IP65 HLG-40H-24A
4400
£44.00
Unit price perEstimated delivery between January 23 and January 25.
| Download Datasheet |
|
| Product Details – Model: HLG-40H-24A | |
|---|---|
| Features | |
| Output Type | Constant Voltage / Mix Mode (CV + CC) |
| Rated Power | 40 W |
| Output Voltage | 24 V DC |
| Rated Current | 1.67 A |
| Input Voltage Range | 90-305 VAC / 127-431 VDC :contentReference[oaicite:0]{index=0} |
| Efficiency | Up to ~88-90% typical at full load :contentReference[oaicite:1]{index=1} |
| Protections | Short circuit / Over current / Over voltage / Over temperature :contentReference[oaicite:2]{index=2} |
| IP Rating | IP65 – suitable for outdoor/damp environments :contentReference[oaicite:3]{index=3} |
| Mechanical & Environmental | |
| Operating Temperature | −40 °C to +80 °C case (derating applies) :contentReference[oaicite:4]{index=4} |
| Dimensions (L × W × H) | 171 × 61.5 × 36.8 mm :contentReference[oaicite:5]{index=5} |
| Weight | ~0.73 kg :contentReference[oaicite:6]{index=6} |
| Safety & Compliance | EN61347-1, EN61347-2-13, IP65, CE & other regional marks :contentReference[oaicite:7]{index=7} |
CV 24V-HLG-40W- Non Dimmable LED Driver, IP65 HLG-40H-24A
4400
£44.00
Unit price perEstimated delivery between January 23 and January 25.
Pay with
Your transaction is protected with advanced security measures to keep your information confidential
4400
£44.00
Unit price per| Download Datasheet |
|
| Product Details – Model: HLG-40H-24A | |
|---|---|
| Features | |
| Output Type | Constant Voltage / Mix Mode (CV + CC) |
| Rated Power | 40 W |
| Output Voltage | 24 V DC |
| Rated Current | 1.67 A |
| Input Voltage Range | 90-305 VAC / 127-431 VDC :contentReference[oaicite:0]{index=0} |
| Efficiency | Up to ~88-90% typical at full load :contentReference[oaicite:1]{index=1} |
| Protections | Short circuit / Over current / Over voltage / Over temperature :contentReference[oaicite:2]{index=2} |
| IP Rating | IP65 – suitable for outdoor/damp environments :contentReference[oaicite:3]{index=3} |
| Mechanical & Environmental | |
| Operating Temperature | −40 °C to +80 °C case (derating applies) :contentReference[oaicite:4]{index=4} |
| Dimensions (L × W × H) | 171 × 61.5 × 36.8 mm :contentReference[oaicite:5]{index=5} |
| Weight | ~0.73 kg :contentReference[oaicite:6]{index=6} |
| Safety & Compliance | EN61347-1, EN61347-2-13, IP65, CE & other regional marks :contentReference[oaicite:7]{index=7} |
