CV-24V-HLG-80W- Non Dimmable LED Driver, IP65 HLG-80H-24A
5000
£50.00
Unit price perEstimated delivery between January 23 and January 25.
| Download Datasheet |
|
| Product Details – Model: HLG-80H-24A | |
|---|---|
| Features | |
| Rated Power | ≈ 81.6 W |
| Output Voltage | 24 V DC |
| Input Voltage Range | 90-305 VAC / 127-431 VDC :contentReference[oaicite:0]{index=0} |
| Efficiency | Up to ~91% :contentReference[oaicite:1]{index=1} |
| IP Rating | IP65 (some variants IP67) :contentReference[oaicite:2]{index=2} |
| Protections | Short Circuit / Over Current / Over Voltage / Over Temperature :contentReference[oaicite:3]{index=3} |
| Cooling | Fanless, convection cooling :contentReference[oaicite:4]{index=4} |
| Output & Physical Specs | |
| Rated Current | 3.4 A :contentReference[oaicite:5]{index=5} |
| Output Voltage Typical Range | ~22-27 V (actual adjustment via potentiometer) :contentReference[oaicite:6]{index=6} |
| Dimensions (L × W × H) | 195.6 × 61.5 × 38.8 mm :contentReference[oaicite:7]{index=7} |
| Operating Temperature | −40 °C to +80 °C case (derating applies at high ambient) :contentReference[oaicite:8]{index=8} |
| Weight | ~0.84 kg :contentReference[oaicite:9]{index=9} |
| Other Specs & Notes | |
| Dimming Capability | Non-dimmable for this model; however internal potentiometer allows minor voltage / current adjustment :contentReference[oaicite:10]{index=10} |
| Lifespan | > 62,000 hours typical life expectancy :contentReference[oaicite:11]{index=11} |
| Warranty | 7 Years (manufacturer) :contentReference[oaicite:12]{index=12} |
| Typical Applications | Outdoor signage / architectural lighting / LED strips / lighting for harsh or damp conditions :contentReference[oaicite:13]{index=13} |
