CV-24V-HLG-185W- Non Dimmable LED Driver, IP65 HLG-185H-24A
7400
£74.00
Unit price perEstimated delivery between January 23 and January 25.
| Download Datasheet |
|
| Product Details ‒ Model: HLG-185H-A Series | |
|---|---|
| Features | |
| Power Rating | ~185 W |
| AC Input Range | 90-305 VAC / 127-431 VDC |
| Efficiency | Up to 94% |
| IP Rating | IP65 / IP67 (Indoor & Outdoor) |
| Protections | Short-Circuit / Over-Current / Over-Voltage / Over-Temperature |
| Cooling | Free-air convection, fanless |
| Output Specifications | |
| Available Output Voltages | 12V, 15V, 20V, 24V, 30V, 36V, 42V, 48V, 54V |
| Environmental & Mechanical | |
| Operating Temp | -40 °C to +70 °C (case), with derating |
| Dimensions (L × W × H) | 228 × 68 × 38.8 mm |
| Other Specifications | |
| Warranty | 7 years (manufacturer) :contentReference[oaicite:10]{index=10} |
| Typical Life Expectancy | > 62,000 hours :contentReference[oaicite:11]{index=11} |
