HW5 MiBoxer 5-In-1 Receiver / Controller WiFi + 2.4G RF (30A)

5-in-1 LED Controller — RF, Wi-Fi & MESH Networking (30A)

The MiBoxer HW5 is a high-current 5-in-1 receiver and controller for 12V to 48V DC LED strips, supporting up to 30A maximum output. It can be controlled wirelessly via 2.4GHz RF handsets, wall panels, or the Tuya app on your smartphone or smart speaker — no gateway required. The unit can be set to single colour dimming, colour temperature (CCT), RGB, RGBW, or RGB+CCT mode, with the indicator light showing the active colour mode. Push Dimming allows a momentary push switch to be wired directly to the unit for manual switching and dimming. Multiple receivers can synchronise wirelessly to form a MESH network, with each unit passing signal to the next (up to 30m apart) — no interconnecting control cables needed. The “Do Not Disturb” function returns the lighting to its last state or off should power be interrupted. PWM frequency is selectable at 250Hz or 16KHz to minimise flicker and banding. Suitable for commercial and domestic installations.

Key Features

• 5-in-1 Mode — single colour dimming, CCT, RGB, RGBW, RGB+CCT
• High Current Output — up to 30A maximum, ideal for larger installations
• RF + Wi-Fi Control — compatible with all 2.4GHz Mi-Light / Mi-Boxer handsets and wall panels
• MESH Networking — receivers sync wirelessly, up to 30m between each unit
• Push Dimming — wire a momentary push switch directly to the receiver
• Do Not Disturb — returns to last setting or off state after a power interruption
• Tuya App Compatible — smartphone and smart speaker control, no gateway required
• Adjustable PWM Frequency — 250Hz or 16KHz to reduce flicker and banding
• 5-Year Guarantee

What's in the Box

• HW5 5-in-1 RF (2.4G) & WiFi Receiver / Controller
• Instruction manual

For more information on this or any of our Mi-Light / Mi-Boxer range of products, please contact our technical sales team by phone, email, or via live chat and WhatsApp on our website.
