E2WR MiBoxer 2-In-1 Controller / Receiver WiFi / 2.4G RF (12V & 24V)
Estimated delivery between August 07 and August 09.
2-in-1 LED Controller — RF, Wi-Fi & MESH Networking
The MiBoxer E2WR is a compact 2-in-1 receiver and controller for 12V and 24V DC LED strips, offering wireless control via 2.4GHz RF handsets, wall panels, or the Tuya app on your smartphone or smart speaker — no gateway required. It can be set to single colour dimming or colour temperature (CCT) mode, with the indicator light glowing red for single colour and green for dual colour (CCT). Push Dimming allows a momentary push switch to be wired directly to the unit for manual switching and dimming. Multiple receivers can synchronise wirelessly to form a MESH network, with each unit passing signal to the next (up to 30m apart) — no interconnecting control cables needed. The “Do Not Disturb” function returns the lighting to its last state or off should power be interrupted. PWM frequency is selectable at 250Hz or 16KHz to minimise flicker and banding. Suitable for commercial and domestic installations.
Key Features
- 2-in-1 Mode — single colour dimming or CCT (colour temperature adjustable)
- RF + Wi-Fi Control — compatible with all 2.4GHz Mi-Light / Mi-Boxer handsets and wall panels
- MESH Networking — receivers sync wirelessly, up to 30m between each unit
- Push Dimming — wire a momentary push switch directly to the receiver
- Do Not Disturb — returns to last setting or off state after a power interruption
- Tuya App Compatible — smartphone and smart speaker control, no gateway required
- Adjustable PWM Frequency — 250Hz or 16KHz to reduce flicker and banding
- 5-Year Guarantee
| Product Details — Model: E2WR | |
|---|---|
| Electrical | |
| Input Voltage | 12V / 24V DC |
| Output Voltage | 12V / 24V DC |
| Max Output Current | 12A |
| Rated Current per Channel | 6A |
| Voltage Type | Constant Voltage |
| PWM Frequency | 250Hz or 16KHz (selectable) |
| Connectivity | |
| Wireless Protocol | 2.4GHz RF & Wi-Fi |
| Frequency Range | 433MHz |
| Wireless Range | Up to 500 metres |
| App Control | Tuya (no gateway required) |
| Physical | |
| IP Rating | IP20 Non-Waterproof |
| Operating Temperature | −10°C to +40°C |
| General | |
| Manufacturer | Mi-Light / MiBoxer |
| LED Strip Brands | Mi-Light / MiBoxer |
| Product Type | Controller / Receiver |
| Product Code | E2WR |
| Guarantee Period | 5 Years |
| Packaging | Gift box |
What's in the Box
- E2WR Receiver / Controller
- Adhesive pad
- Instruction manual
For more information on this or any of our Mi-Light / Mi-Boxer range of products, please contact our technical sales team by phone, email, or via live chat and WhatsApp on our website.
Downloads
| Product Documentation | |
|---|---|
| Data Sheets & Manuals | |
| E2WR MiBoxer 2-In-1 Controller — Product Data Sheet | |
For more information on this or any of our Mi-Light / Mi-Boxer range of products, please contact our technical sales team by phone, email, or via live chat and WhatsApp on our website.
