Hager MCB 1P 6kA B-16A 1M MTN116
£1.99
Unit price perEstimated delivery between September 27 and September 29.
Hager MTN116 16A Type B 1P Miniature Circuit Breaker
The Hager MTN116 miniature circuit breaker provides overload and short-circuit protection for single-phase circuits. Its 16A Type B characteristic suits circuits with relatively low inrush current, while the compact one-module design conserves distribution-board space. Screw and bi-connect terminals, together with flexible 360° mounting, support straightforward installation.
Key Features
- 16A Type B Protection: Designed for circuits with relatively low switching surges.
- 6kA Breaking Capacity: Rated to IEC 60898-1 at 230V AC.
- Single-Pole Design: Compact 1P breaker occupying one 17.5mm module.
- Flexible Connections: Screw top terminal and bi-connect bottom terminal accept rigid and flexible conductors.
- Wide Operating Range: Suitable for operating temperatures from -25°C to 70°C.
- Compact Installation: Supports 360° mounting and uses a 35mm grid distance.
Technical Specifications
| Product Details | |
|---|---|
| Brand | Hager |
| Model / SKU | MTN116 |
| Product Type | Miniature circuit breaker (MCB) |
| EAN | 3250614343049 |
| Electrical | |
| Rated Current | 16 A |
| Tripping Curve | B |
| Number of Poles | 1P |
| Rated Operational Voltage | 230–400 V AC |
| Frequency | 50–60 Hz |
| Breaking Capacity | 6 kA to IEC 60898-1 |
| Rated Insulation Voltage | 500 V |
| Rated Impulse Withstand Voltage | 4,000 V |
| Power Dissipation at Rated Current | 2.44 W |
| Energy Limitation Class I²t | 3 |
| Installation & Connections | |
| Number of Modules | 1 |
| Top Connection | Screw terminal, aligned |
| Bottom Connection | Bi-connect, aligned |
| Rigid Conductor Capacity | 1–35 mm² |
| Flexible Conductor Capacity | 1–25 mm² |
| Nominal Tightening Torque | 2.80 Nm, top and bottom terminals |
| 360° Mounting Position | Yes |
| Grid Distance | 35 mm |
| Safety & Operating Conditions | |
| Ingress Protection | IP20 |
| Pollution Degree | 2, according to IEC 60664 / IEC 60947-2 |
| Air Humidity Protection | For all climates |
| Operating Temperature | -25°C to 70°C |
| Dimensions | |
| Height | 83 mm |
| Width | 17.50 mm |
| Depth | 70 mm |
| Temperature Derating Data | |
| Rated Current at -15°C | 21.19 A |
| Rated Current at -10°C | 20.89 A |
| Rated Current at -5°C | 20.17 A |
| Rated Current at 0°C | 19.66 A |
| Rated Current at 5°C | 19.16 A |
| Rated Current at 10°C | 18.65 A |
| Rated Current at 15°C | 18.14 A |
| Rated Current at 20°C | 17.63 A |
| Rated Current at 25°C | 17.13 A |
| Rated Current at 30°C | 16 A |
| Rated Current at 35°C | 16.11 A |
| Rated Current at 40°C | 15.60 A |
| Rated Current at 45°C | 15.10 A |
| Rated Current at 50°C | 15 A |
| Rated Current at 55°C | 14.08 A |
| Rated Current at 60°C | 13.57 A |
| Rated Current at 65°C | 13.07 A |
| Rated Current at 70°C | 12.56 A |
What's in the Box
- 1 x Hager MTN116 16A Type B single-pole miniature circuit breaker
Need help confirming compatibility with your distribution board or circuit? Contact The Lighting Gallery team before ordering and we’ll be happy to assist.
